Phone Cable Plastic Injection Molding Machine JY-200ST

Name: Phone Cable Plastic Injection Molding Machine JY-200ST
Brand: Twist Tie Machines & Packaging Solutions
SKU: JY-200ST
Availability: InStock
Rating: 5 (1 reviews)

Model No: JY-200ST
Phone Cable Wire Injection Moulding Machine, Cable Wire Making Machine, Mobile Phone Cable Weir Injection Machine
Model Unit JY-200ST
Screw Barrel Diameter mm 26 28
Injection Pressure kg/cm2 1019 896
Max. Shot Weight gram 58 67
Max. Shot Weight cm3/sec 67 76.7
Screw Barrel Route mm 105
Screw Barrel Rotary Speed rpm 0-200
Nozzle Contact Force tons 4.45
Nozzle Retraction Nozzle mm 130
Number of Temperature Control pcs 2
Inquiry now

Detailed description

Phone Cable Wire Injection Moulding Machine, Cable Wire Making Machine, Mobile Phone Cable Weir Injection Machine

Specification

Model Unit JY-200ST
Screw Barrel Diameter mm 26 28
Injection Pressure kg/cm2 1019 896
Max. Shot Weight gram 58 67
Max. Shot Weight cm3/sec 67 76.7
Screw Barrel Route mm 105
Screw Barrel Rotary Speed rpm 0-200
Nozzle Contact Force tons 4.45
Nozzle Retraction Nozzle mm 130
Number of Temperature Control pcs 2
Clamping Force tons 25
Platen Size mm 480*310
Distance Between Tie Bere mm 310*170
Min. Mold Height mm 100/60
Opening Stroke mm 180
Max. Opening Mold Distance mm 280/80
Ejetor Force tons 1.3
Ejector Stoke mm 35
Max. Hydraulic Pressure kg/cm2 140
Pump Output L/min 29.5
Oil Reservoir Capacity Liter 100
Cooling Water Consumption L/hr 400-600
Pump Motor Power kW/hp 3.75HP
Barrel Heating Power kW 1.8
Total Power kW 5.5
Machine Weight tons 0.68
Machine Dimension(LxWxH) meter 1.4*0.90*2.37
Shipping Weight tons 0.88
Shipping Measurements(LxWxH) meter 1.49*1.08*2.25
Product Drawing

Phone Cable Wire Injection Moulding Machine, Cable Wire Making Machine

Product Features

1)Straight screw ejected assembly.
2)Two(three)-phase temperature, ejected speed, backing pressure, and screw speed is suitable for various plastic to be confectioned.
3)Low-die fixed top active mode makes inserted objects excellent positioned features and the machine has left out the attachment for finished goods.
4)Low-pressure closed die assembly can protect the safety of the die.
5)Material tube can be lifted. It is easy to clean the stub bar. It is easy to fix the die.
6)Can be installed on a single mold or double shuttle table.

Application

Phone Cable Wire Injection Moulding Machine, Cable Wire Making Machine
