Automatic 8 Shape Wire Winding and Tying Machine WPM-81

Name: Automatic 8 Shape Wire Winding and Tying Machine WPM-81
Brand: Twist Tie Machines & Packaging Solutions
SKU: WPM-81
Availability: InStock
Rating: 5 (1 reviews)

Model No: WPM-81
Full automatic wire winding and tying machine, wire twisting tie machine, automatic string tying machine.
Full wire winding tying machine
Wire/cable type AC / DC / USB etc.
Wire outer diameter ≤ 6.2 mm
Winding part distance 70 - 200 mm
Winding length ≤ 6 m
Winding speed Adjustable
Tying outer diameter ≤ 55 mm
Wirehead length 0 - 130 mm
Wire tail length > 0 mm
Inquiry now

Detailed description

Full automatic wire winding and tying machine, wire twisting tie machine, automatic string tying machine.
wire winding tying machine
Model WPM-81
Finished product 8 shapes, single tying
Wire/cable type AC / DC / USB etc.
Wire outer diameter ≤ 6.2 mm
Winding part distance 70 - 200 mm
Winding length ≤ 6 m
Winding speed Adjustable
Tying outer diameter ≤ 55 mm
Wirehead length 0 - 130 mm
Wire tail length > 0 mm
Productivity 1800 pcs./h (winding length = 1 m, number of turns = 3)
Compressed air connection 0.55 - 0.65 MPa
Power supply 110, 220 V (50 - 60 Hz)
Power 2 kW
Dimension 1040 * 720 * 1540 mm
Weight 160 kg
